Concrete shuttering and formwork in West Cork

Shuttering in construction is the temporary or permanent mould that holds wet concrete to shape until it has set and gained enough strength to stand on its own. Euro Concrete Services builds shuttering for footings, floor slabs, cast walls, tanks and slurry pits in West Cork, and strikes it after the pour.

Temporary shuttering is made of timber, plywood or steel panels, held in line with props, soldiers, walers and ties, then taken down and reused. Permanent shuttering stays as part of the structure, as with insulated concrete formwork or precast units. Either way it has to resist the full pressure of wet concrete, which pushes hardest at the base of a tall wall, so it is braced to hold its line and level through the pour. The face of the shuttering becomes the face of the concrete: a clean, sealed panel gives a smooth, straight finish, while a gap or a bowed board shows in the wall for good.

Formwork and shuttering mean the same thing in everyday use: the mould that wet concrete is poured into and held by until it sets. Euro Concrete uses both words for the same work, and in Ireland shuttering is the word people search for far more often.

Where the two are separated, shuttering refers to the sheeting or panels in contact with the concrete, which give it its shape and surface, and formwork to the whole temporary system around them: the panels plus the soldiers, walers, ties, props and bracing that hold them in position and carry the load. Falsework is a third term, for the supporting structure that holds formwork up at height, such as the frames under a suspended slab or a bridge deck. You will see formwork on engineers' drawings and hear shuttering on site; the job is the same, and so is the care needed to get line, level and finish right before the concrete arrives.

The time shuttering stays on depends on what it is forming, the concrete mix and the weather. Euro Concrete strikes wall and column shuttering once the concrete can hold its own shape, and leaves the supports under a slab or beam in place until the engineer confirms the concrete can carry itself.

Vertical shuttering on walls, columns and the sides of foundations carries no load once the concrete has set, so it can come off early, as soon as striking will not damage the face. The shuttering and props under a slab or beam carry the weight of the concrete, so they stay until the concrete is strong enough, which takes longer. Cold weather slows the concrete gaining strength, so shuttering stays on longer in winter, and warm weather speeds it up. On structural work, the engineer's specification sets the striking times, and cube tests can be used to confirm the strength before the props come out.

No. Euro Concrete does not hire out shuttering or formwork on its own. The shuttering we build is for our own concrete work, so the forming, the pour and the striking are done by one crew wherever the job is in West Cork.

If you were planning to hire shuttering to cast a wall, a tank or a foundation yourself, ring us with the job instead, and we will price the forming as part of the concrete work. That puts the setting out, the bracing, the checks on line and level before the lorry arrives, the pour and the striking in the same hands. On a big pour, it also means the shuttering is built to take the pressure of the concrete coming in. For the supply of a formwork system on its own, a formwork hire company is the right call. Send us the drawings or the sizes with the location, and the price covers the whole job.

Euro Concrete prices shuttering as part of the concrete job it forms, based on the size and height of what is being cast, the finish it needs, the number of pours, and the access to the site. Ring Sean on 086 881 9848 with the drawings or the sizes, and we will price the forming and the pour together.

Height matters most on walls and tanks, since taller shuttering takes more concrete pressure and needs more ties, bracing and time to erect. Shape comes next: long straight runs go up quickly, while corners, openings, steps and curves slow the work. A fair-faced finish left on show needs cleaner panels and more care than concrete that will be backfilled or clad. Each pour means fixing and striking the shuttering again, so fewer, larger pours save time where the design allows. On rural sites, access for the concrete lorry and any pump changes the day as well.

Euro Concrete Services is a shuttering contractor based in Skibbereen, working across West Cork, forming foundations, walls, tanks and slabs on farms, building sites and house sites. Ring Sean on 086 881 9848 with the site, the element to be cast, and any drawings or sizes.

The shuttering covers Bandon, Clonakilty and Dunmanway, Drinagh and Drimoleague, Leap and Glandore, Skibbereen itself, and out to Bantry and Schull. Farms with long lanes and sites with no hard standing are included, so describe the access when you ring. On a site at the far end of the area, the pours can be planned so the crew makes the fewest trips, with the drawings agreed and the concrete booked before we arrive. Say whether you want the concrete priced as well as the forming, and how the lorry will reach the pour, since both shape how the shuttering day is planned.
